Used Die Cutter Royo Machinery RSL-1060 MT

Paper or cardboard thickness: 100-2000 gsm, Die cutting Precision: +/- 0.15mm, Voltage: 220V 3PH 60Hz, Step-less speed control, Pre-loader, Max. Foil stamping size: 1050 x 745mm, Suggested HS code: 8441.4000 (Automatic), Total Power: 21kw, Corrugated board up to 4mm, Pull or Push side lay on both sides, Min. Paper size: 400 x 350mm, Total Weight: 21 Tons, Central lubrication with auto pump , Programmable foil advance, Heating System, Foil Stamping, Pneumatic flap for test sheet removal, Max. Speed: 7500 strokes per hour, Max. Foil Stamping Speed: 6500 strokes per hour , CE Standard Machine, Air clutch, Max. paper size: 1060 x 760mm, Max. Foil Roll Diameter: 200mm (Cross advance), Max. Foil Roll Diameter: 250mm (Longitudinal advance), Max. die cutting pressure: 260 Tons, Max. die cutting size: 1055 x 750mm, Max. Foil advance: 800mm, Heavy Duty, Gripper Margin: 8-17 mm, Heating Zones: 20, Feeding Pile Height: 1250mm, Dimensions: 7570 x 4650 x 2280 mm, Delivery Pile Height 1000 mm, Die cutting chase pneumatic locking mechanism, Foil feeding units: 3 (Longitudinal advance) , Foil feeding units: 2 (Transversal advance)
