Die Cutter - Search Results

Die Cutter 1979 Gietz FSA 720, S/N: 11406, Paper size: 520 x 720 mm, Features: , Dimensions: 4.3 x 3.6 x 1.9 m, Feeding Pile Height: 950mm, Foil Stamping, Foil feeding units: 3, Max. Paper Thickness: 0.5mm, Max. Sheet Size: 720 x 520 mm, Max. Speed: 5000 sph , Maximum foil diameter: 160mm 1" core, Min. Paper size: 297 x 210mm, Programmable foil advance, Total Power: 34kw, Total Weight: 7.0 Tons .

Die Cutter 2018 Royo Machinery RDC-1060C, S/N: 18051-3-10, Paper size: 750 x 1050 mm, Features: , Central lubrication with auto pump , Corrugated board up to 4mm, Delivery Pile Height 1100 mm, Die cutting Precision: +/- 0.15mm, Dimensions: 4990 x 2700 x 2060 mm, Feeding Pile Height: 1380mm, Max. Speed: 8000 strokes per hour, Max. die cutting pressure: 250 Tons, Max. die cutting size 1060 x 780mm, Min. Paper size: 450 x 360mm, Min. gripper margin: 5mm, Paper or cardboard thickness: 100-2000 gsm, Total Power: 18kw, Total Weight: 17 Tons, Voltage: 220V 3PH 60Hz.

Die Cutter 2024 Royo Machinery ML1100, S/N: 749675, Paper size: 720 x 1020 mm, Features: , Central lubrication with auto pump , Dimensions: 2020 x 2010 x 1900 mm, Hand Feed, Max. Speed: 1200 strokes per hour, Max. die cutting length: 3000 mm, Max. die cutting size 1100 x 800mm, Paper or cardboard thickness: 100-2000 gsm, Specifications are subject to change without notice, Suitable paper 1-8 mm corrugated paper (including laminated), Total Power: 5.5kw, Total Weight: 4.5 Tons , Total Weight: 6 Tons , Voltage: 220V 3PH 60Hz.

Die Cutter 2025 Royo Machinery ML2500, S/N: 759870B, Paper size: 2500 x 1500 mm, Features: , 5mm steel plate, Air clutch, CE Standard Machine, Central lubrication with auto pump , Corrugated board up to 8.5mm, Cycle control: Single cut and stop at the open position - time delay open position - continuous cycle, Dimensions: 142" x 88.5" x 98.5", Dust cover curtain, Gantry for chase removal, Hand Feed, IR safety lights, Inner chase size: 98.5" x 59", Max. Speed: 12 +/-2 strokes per minute, Max. die cutting length: 2756", Micro adjustment device, Paper or cardboard thickness: 100-2000 gsm, Pneumatic die plate ejector, Suggested HS code: 8443.19.8000 (Manual), Total Power: 22kw, Total Weight: 18.5 Tons, Triple electromechanical safety device, Voltage: 220V 3PH 60Hz.

Die Cutter 2024 Royo Machinery ML750, S/N: 749780B, Paper size: 530 x 750 mm, Features: , Central lubrication with auto pump , Dimensions: 1650 x 1400 x 1500 mm , Hand Feed, Max. Speed: 1500 strokes per hour, Max. die cutting length: 1500 mm, Max. die cutting size: 750 x 520mm, Paper or cardboard thickness: 100-2000 gsm, Suitable paper 1-8 mm corrugated paper (including laminated), Total Power: 2.2kw, Total Weight: 2.2 Tons , Voltage: 220V 3PH 60Hz.

Die Cutter 2017 Guowang C130Y, S/N: 1302, Paper size: 1060 x 760 mm, Features: , Delivery pile height: 1350 mm, Dimensions: 6264 x 4850 x 2580 mm, Feeding Pile Height: 1600 mm, Gripper Margin: 9-17 mm, Heating temperature: 0-200°C, Heating zones: 20, Machine control via color touch screen, Max. Foil Stamping Speed: 6500 strokes per hour, Max. Foil stamping size: 1040 x 740mm, Max. die cutting pressure: 350 Tons, Max. die cutting size 1045 x 745 mm, Min. Paper size: 450 x 370mm, Programmable foil advance, Total Power: 35kw, Total Weight: 19 Tons.

Die Cutter 2026 Royo Machinery RHT-1050, S/N: Pending, Paper size: 740 x 1050 mm, Features: , Air clutch, Automatic pressure adjustment, Central lubrication with auto pump , Corrugated board up to 4mm, Delivery Pile Height 1100 mm, Die cutting chase pneumatic locking mechanism, Die cutting precision: +/- 0.075mm, Digital LED control panel, Dimensions: 4820 x 3865 x 2200mm, Feeding Pile Height: 1280mm, Machine control via color touch screen, Max. Speed: 7500 strokes per hour, Max. die cutting pressure: 300 Tons, Max. die cutting size: 1040 x 730mm, Max. feeding pile height: 1280mm, Max. paper size: 1050 x 740mm, Min. gripper margin: 9mm, Min. paper size: 400 x 360mm, Non-stop feeder and delivery, Paper or cardboard thickness: 80-2000 gsm, Pull or Push side lay on both sides, Step-less speed control, Suggested HS code: 8441.4000 (Automatic), Total Power: 16kw, Total weight: 15 Tons, Voltage: 220V 3PH 60Hz.

Die Cutter 2021 Royo Machinery RDC-800M, S/N: 8020391, Paper size: 610 x 820mm, Features: , Central lubrication with auto pump , Corrugated board up to 2mm, Delivery Pile Height: 1030mm, Die cutting Precision: +/- 0.15mm, Dimensions: 4290 x 2330 x 1980 mm, Inner chase size: 815 x 620 mm, Max. Speed: 8500 strokes per hour, Max. die cutting pressure: 150 Tons, Max. die cutting size 800 x 620mm, Min. gripper margin: 7 mm, Non-stop feeder and delivery, Paper or cardboard thickness: 80-2000 gsm, Pre-loader, Suggested HS code: 8441.4000 (Automatic), Total Power: 14kw, Total weight: 11.5 Tons, Voltage: 220V 3PH 60Hz.
