Die Cutter RMHK-1300FC Features: Suitable paper 1-8 mm corrugated paper (including laminated), Non-stop delivery with rolling curtain, Step-less speed control, Total Power: 22kw, Total Weight: 22 Tons, Central lubrication with auto pump, Die cutting chase pneumatic locking mechanism, Digital LED control panel, CE Standard Machine, Automatic pressure adjustment, Air clutch, Specifications are subject to change without notice, Suggested HS code: 8441.4000 (Automatic), Stock range: E B C A and AB flute corrugated board (1-8.5mm), Recommended height of cutting rules: 23.8mm, Pull or Push side lay on both sides, Min. Paper size: 470 x 450mm, Max. Speed: 6000 strokes per hour, Max. Speed with stripping: 6000 strokes per hour, Max. paper size: 1290 x 940mm, Max. die cutting size 1280 x 920mm, Inner chase size: 51.5" x 37.3", Gripper Margin: 9-17 mm, Die cutting Precision: +/- 0.15mm, Air pressure: 7 bar - 1.0 m3/min, Dimensions: 10630 x 4820 x 2400 mm, Lead edge feeder with top loading, Hydraulic scissor lift, Remote service ready, Machine control via color touch screen, First cutting rule: 12mm, Ultrasonic & Mechanical double-sheet detector.
Die Cutter RBHT-1060SCE Features: Suggested HS code: 8441.4000 (Automatic), Ultrasonic & Mechanical double-sheet detector, Step-less speed control, Recommended height of cutting rules: 23.8mm, Pull or Push side lay on both sides, Pre-loader, Pneumatic die plate ejector, Dimensions: 10298 x 5857 x 2657 mm, Paper or cardboard thickness: 0.1-2.0 mm, Non-stop feeder and delivery, Total Weight: 22 Tons, Motorized front lays with optical monitoring, Min. Paper size: 400 x 350mm, Micro adjustment device, Heavy duty gripper bars, Max. paper size: 1060 x 760mm, Max. Speed: 8000 strokes per hour, Gripper Margin: 9-17 mm, Digital LED control panel, Die cutting chase pneumatic locking mechanism, Corrugated board up to 4mm, Central lubrication with auto pump, CE Standard Machine, Automatic pressure adjustment, Total Power: 26kw, Paper or cardboard thickness: 80-2000 gsm, Max. Speed with stripping: 7000 strokes per hour, Max. die cutting size 1060 x 745 mm, Max. die cutting pressure: 300 Tons, Inner chase size: 1080 x 770 mm, Feeding Pile Height: 1800 mm, Delivery Pile Height 1520 mm, Blanking unit with automatic pile ejector, Auto separation sheet inserting mechanism, Air clutch, Advance stripping and blanking tooling lockup, 4+1 mm combination steel plate.
Die Cutter ML1600 Features: Voltage: 220V 3PH 60Hz, Triple electromechanical safety device, Total weight: 11.5 Tons, Total Power: 11kw, Suggested HS code: 8443.19.8000 (Manual), Recommended height of cutting rules: 23.8mm, IR safety lights, Hand Feed, Heating System, Inner chase size: 63" x 49.25" mm, Dust cover curtain, Dimensions: 112.25" x 88.5" x 82.75", Cycle control: Single cut and stop at the open position - time delay open position - continuous cycle, Central lubrication with auto pump, Air pressure: 7 bar - 0.3 m3/min, Air clutch, 5mm steel plate, Max. die cutting length: 1968", Gantry for chase removal, Specifications are subject to change without notice.
Die Cutter RMHC-1060CE Features: Voltage: 220V 3PH 60Hz, Total Power: 11kw, Suggested HS code: 8441.4000 (Automatic), Step-less speed control, Recommended height of cutting rules: 23.8mm, Pre-loader, Non-stop feeder and delivery, Min. Paper size: 400 x 350mm, Max. Speed: 7500 strokes per hour, Max. paper size: 1060 x 760mm, Max. die cutting pressure: 300 Tons, Inner chase size: 1120 x 786 mm, Frontal back and side registration mechanism, Die cutting Precision: +/- 0.15mm, Feeding Pile Height: 1600mm, Delivery Pile Height 1400 mm, Corrugated board up to 4mm, Central lubrication with auto pump, CE Standard Machine, Automatic pressure adjustment, Air pressure: 7 bar - 0.3 m3/min, Air clutch, Specifications are subject to change without notice.
Die Cutter RMHK-2S1050TMC Duopress Features: Step-less speed control, Suggested HS code: 8441.4000 (Automatic), Recommended height of cutting rules: 23.8mm, Programmable foil advance, Pre-loader, Non-stop feeder and delivery, Min. paper size: 400 x 360mm, Gripper Margin: 9-17 mm, Foil Stamping, Feeding Pile Height: 1600mm, Digital LED control panel, Die cutting precision: +/- 0.075mm, Die cutting chase pneumatic locking mechanism, Corrugated board up to 4mm, Delivery Pile Height 1400 mm, Central lubrication with auto pump, CE Standard Machine, Paper or cardboard thickness: 80-2000 gsm, Automatic pressure adjustment, Total Weight: 34 Tons, Air clutch, Total Power: 72kw, Pull or Push side lay on both sides, Max. Speed with stripping: 7200 strokes per hour, Max. Foil Stamping Speed: 7200 strokes per hour, Max. Foil stamping size: 1040 x 720mm, Max. paper size: 1050 x 750mm, Max. foil diameter: 250mm (Vertical) 200mm (Horizontal), Max. die cutting pressure: 600+300 Tons, Inner chase size: 1080 x 745 mm, Heating Zones: 20, Foil width: 20-1020mm, Foil feeding units: 3 (Longitudinal advance), Foil feeding units: 2 (Transversal advance), Air pressure: 7 bar - 1.0 m3/min, Max. die cutting size: 1040 x 720mm, Paper or cardboard thickness: 0.1-2.0 mm, Specifications are subject to change without notice.
Die Cutter RHT-810S Features: Total Weight: 13 Tons, Total Power: 18kw, Recommended height of cutting rules: 23.8mm, Min. paper size: 320 x 260 mm, Min. gripper margin: 7 mm, Max. Speed: 9000 strokes per hour, Max. paper size: 810 x 610 mm, Max. feeding pile height: 1480 mm, Max. die cutting size: 800 x 600 mm, Max. die cutting pressure: 500 Tons, Delivery pile height: 1360 mm, Inner chase size: 815 x 620 mm, First cutting rule: 12mm, Die cutting precision: +/- 0.075mm, Corrugated board up to 4mm, Paper or cardboard thickness: 80-2000 gsm, Specifications are subject to change without notice.
Die Cutter RHT-810T Features: Total Weight: 13 Tons, Total power: 45kw, Recommended height of cutting rules: 23.8mm, Min. Paper size: 320 x 260mm, Min. gripper margin: 7 mm, Min. distance to 1st rule: 12 mm, Max. paper size: 820 x 610 mm, Max. hologram speed: 7500s/h, Max. Foil Stamping Speed: 9000 strokes per hour, Max. Foil stamping size: 780 x 580 mm, Max. feeding pile height: 1480 mm, Max. die cutting size: 800 x 600 mm, Delivery pile height: 1360 mm, Max. die cutting pressure: 500 Tons, Inner chase size: 815 x 620 mm, Heating zones: 10, Heating temperature: 0-190°C, Feeding shaft: 3/6 (Option), Die cutting precision: +/- 0.075mm, Corrugated board up to 4mm, Paper or cardboard thickness: 80-2000 gsm, Specifications are subject to change without notice.
Die Cutter RHT-1060T Features: Air clutch, Automatic pressure adjustment, Central lubrication with auto pump, Max. die cutting pressure: 300 Tons, Frontal back and side registration mechanism, Foil Stamping, Foil feeding units: 3 (Longitudinal advance), Foil feeding units: 2 (Transversal advance), Feeding Pile Height: 1250mm, Die cutting chase pneumatic locking mechanism, Digital LED control panel, Delivery Pile Height 1100 mm, Corrugated board up to 4mm, Total Weight: 20 Tons, Total Power: 38kw, Paper or cardboard thickness: 0.1-2.0 mm, Non-stop feeder and delivery, Max. Speed: 7500 strokes per hour, Suggested HS code: 8441.4000 (Automatic), Step-less speed control, Programmable foil advance, Pre-loader, Non-stop delivery with rolling curtain, Pneumatic flap for test sheet removal, Max. Foil Stamping Speed: 7500 strokes per hour, Max. Foil stamping size: 970 x 700mm, Max. Foil Roll Diameter: 250mm (Longitudinal advance), Max. Foil Roll Diameter: 200mm (Cross advance), Heating Zones: 16, Dimensions: 5820 x 3865 x 2200mm, CE Standard Machine, Min. Paper size: 400 x 350mm, Specifications are subject to change without notice.
Die Cutter RHT-600 Features: Die cutting precision: +/- 0.075mm, Motorized front lays with optical monitoring, Max. Speed: 10000 strokes per hour, Gripper Margin: 8-17 mm, Digital LED control panel, Central lubrication with auto pump, CE Standard Machine, Automatic pressure adjustment, Air clutch, Total Weight: 5.5 Tons, Total Power: 10W, Frontal back and side registration mechanism, Min. paper size: 280 x 180mm, Max. paper size: 600 x 420mm, Max. feeding pile height: 900 mm, Max. die cutting size: 590 x 410mm, Dimensions: 3166 x 1890 x 1855 mm, Min. gripper margin: 9mm, Min. distance to 1st rule: 8-16mm, Max. die cutting pressure: 180 Tons, Inner chase size: 600 x 430 mm, Delivery pile height: 800 mm, Die cutting chase pneumatic locking mechanism, Suggested HS code: 8441.4000 (Automatic), Step-less speed control, Pull or Push side lay on both sides, Pneumatic flap for test sheet removal, Recommended height of cutting rules: 23.8mm, Die cutting plate size: 600 x 420mm, Corrugated board up to 4mm, Specifications are subject to change without notice.
Die Cutter RMHK-1500EFC Features: Suitable paper 1-8 mm corrugated paper (including laminated), Non-stop delivery with rolling curtain, Step-less speed control, Heavy Duty, Heavy duty gripper bars, Central lubrication with auto pump, Die cutting chase pneumatic locking mechanism, Digital LED control panel, CE Standard Machine, Automatic pressure adjustment, Air clutch, Specifications are subject to change without notice.
Die Cutter RBHT-1650EFC Features: Suitable paper 1-8 mm corrugated paper (including laminated), Step-less speed control, Remote service ready, Heavy duty gripper bars, Heavy Duty, Digital LED control panel, Die cutting chase pneumatic locking mechanism, Central lubrication with auto pump, CE Standard Machine, Automatic pressure adjustment, Air clutch, Total Weight: 38 Tons, Ultrasonic & Mechanical double-sheet detector, Total Power: 38kw, Stock range: E B C A and AB flute corrugated board (1-8.5mm), Max. Speed with stripping: 6000 strokes per hour, Suggested HS code: 8441.4000 (Automatic), Min. distance to 1st rule: 12 mm, Max. paper size: 1650 x 1200mm, Max. die cutting pressure: 400 Tons, Max. die cutting size 1620 x 1180mm, Inner chase size: 1650 x 1230 mm, Frontal back and side registration mechanism, Dimensions: 11700 x 5470 x 2500 mm, Specifications are subject to change without notice, Machine control via color touch screen, Gripper Margin: 9-17 mm, Lead edge feeder with top loading, First cutting rule: 12mm, Die cutting Precision: +/- 0.15mm.
Die Cutter RHT-1060S Features: Air clutch, Automatic pressure adjustment, CE Standard Machine, Central lubrication with auto pump, Total Weight: 17.8 Tons, Total Power: 18kw, Step-less speed control, Pull or Push side lay on both sides, Paper or cardboard thickness: 100-2000 gsm, Min. Paper size: 400 x 350mm, Max. Speed: 8000 strokes per hour, Max. die cutting pressure: 300 Tons, Feeding Pile Height: 1580mm, Digital LED control panel, Die cutting Precision: +/- 0.15mm, Delivery Pile Height 1400 mm, Corrugated board up to 4mm, Specifications are subject to change without notice.
Die Cutter RHT-1060PG Features: Step-less speed control, Pre-loader, Non-stop feeder and delivery, Min. Paper size: 400 x 350mm, Max. Speed: 9000 strokes per hour, Max. Speed with stripping: 8500 strokes per hour, Max. die cutting pressure: 300 Tons, Heavy duty gripper bars, Digital LED control panel, Die cutting Precision: +/- 0.15mm, Die cutting chase pneumatic locking mechanism, Corrugated board up to 4mm, Central lubrication with auto pump, CE Standard Machine, Automatic pressure adjustment, Air clutch, Ultrasonic & Mechanical double-sheet detector, Pull or Push side lay on both sides, Pneumatic flap for test sheet removal, Non-stop delivery with rolling curtain, Motorized front lays with optical monitoring, Min. distance to 1st rule: 8 mm, Voltage: 220V 3PH 60Hz, Total Weight: 20 Tons, Total Power: 20kw, Suggested HS code: 8441.4000 (Automatic), Heavy Duty, Gripper Margin: 9-17 mm, Feeding Pile Height: 1580mm, Delivery Pile Height 1400 mm, Max. paper size: 1060 x 760mm, Max. die cutting size 1050 x 750mm, Specifications are subject to change without notice.
Die Cutter RMHC-1500 Features: Suitable paper 1-8 mm corrugated paper (including laminated), Min. Paper size: 470 x 450mm, Dimensions: 6633 x 4600 x 2300 mm, Max. die cutting size 1480 x 1080mm, Max. paper size: 1500 x 1100mm, Max. Speed: 5000 strokes per hour, Total Weight: 17 Tons, Total Power: 13.5kw, Automatic pressure adjustment, Step-less speed control, Pre-loader, Central lubrication with auto pump, Die cutting chase pneumatic locking mechanism, Digital LED control panel, Hand Feed, Heavy duty gripper bars, Air clutch, Heavy Duty, Specifications are subject to change without notice.
Die Cutter TYMB930 Features: Voltage: 220V 3PH 60Hz, Total Weight: 5 Tons, Total Power: 19kw, Suitable paper 1-8 mm corrugated paper (including laminated), Programmable foil advance, Paper or cardboard thickness: 100-2000 gsm, Max. Speed: 1500 strokes per hour, Max. Foil advance: 800mm, Max. die cutting pressure: 220 Tons, Hand Feed, Foil Stamping, Foil feeding units: 3 (Longitudinal advance), Corrugated board up to 4mm, Central lubrication with auto pump, Specifications are subject to change without notice.
Die Cutter TYMB1100 Features: Paper or cardboard thickness: 100-2000 gsm, Pneumatic die plate ejector, Max. Foil advance: 800mm, Max. die cutting pressure: 220 Tons, Hand Feed, Foil Stamping, Foil feeding units: 3 (Longitudinal advance), Corrugated board up to 4mm, Central lubrication with auto pump, Voltage: 220V 3PH 60Hz, Total Weight: 5 Tons, Total Power: 19kw, Suitable paper 1-8 mm corrugated paper (including laminated), Programmable foil advance, Max. paper Size: 1080 x 780 mm, Max. die cutting size 1100 x 800mm, Dimensions: 2250 x 2200 x 2000 mm, Digital LED control panel, 5mm steel plate, Cycle control: Single cut and stop at the open position - time delay open position - continuous cycle, Air clutch, Micro adjustment device, Max. Speed: 1200 strokes per hour, Heavy Duty, Specifications are subject to change without notice.
Die Cutter ML1100 Features: Voltage: 220V 3PH 60Hz, Paper or cardboard thickness: 100-2000 gsm, Suitable paper 1-8 mm corrugated paper (including laminated), Total Weight: 6 Tons, Max. Speed: 1200 strokes per hour, Max. die cutting size 1100 x 800mm, Max. die cutting length: 3000 mm, Hand Feed, Dimensions: 2020 x 2010 x 1900 mm, Central lubrication with auto pump, Total Weight: 4.5 Tons, Total Power: 5.5kw, Specifications are subject to change without notice.
Die Cutter RHT-760T Features: Central lubrication with auto pump, CE Standard Machine, Automatic pressure adjustment, Voltage: 220V 3PH 60Hz, Non-stop feeder and delivery, Min. Paper size: 320 x 260mm, Max. Speed: 9000 strokes per hour, Max. paper size: 760 x 520mm, Max. die cutting pressure: 250 Tons, Suggested HS code: 8441.4000 (Automatic), Heating System, Foil Stamping, Ultrasonic & Mechanical double-sheet detector, Die cutting Precision: +/- 0.15mm, Delivery Pile Height: 940 mm, Corrugated board up to 4mm, Total Weight: 14 Tons, Total Power: 32kw, Programmable foil advance, Pull or Push side lay on both sides, Pre-loader, Step-less speed control, Foil feeding units: 3 (Longitudinal advance), Pneumatic flap for test sheet removal, Recommended height of cutting rules: 23.8mm, Non-stop delivery with rolling curtain, Min. gripper margin: 7 mm, Min. distance to 1st rule: 12 mm, Inner chase size: 765 x 530mm, Heating Zones: 8, Feeding Pile Height: 1280mm, Max. Foil stamping size: 750 x 510mm, Max. Foil Roll Diameter: 250mm (Longitudinal advance), Feeding Pile Height: 1050mm, Dimensions: 4468 x 2866 x 2309 mm, Digital LED control panel, Air pressure: 7 bar - 0.3 m3/min, Max. Foil Stamping Speed: 9000 strokes per hour, Air clutch, Specifications are subject to change without notice.
Die Cutter ML1300 Features: Total Weight: 6 Tons, Voltage: 220V 3PH 60Hz, Total Power: 7.5kw, Suitable paper 1-8 mm corrugated paper (including laminated), Paper or cardboard thickness: 100-2000 gsm, Max. Speed: 1200 strokes per hour, Max. die cutting size 1280 x 920mm, Max. die cutting length: 1770", Heating System, Hand Feed, Dimensions: 104" x 82.5" x 78.75", Central lubrication with auto pump, CE Standard Machine, Specifications are subject to change without notice.
Die Cutter RHT-760P Features: Total Power: 16.9kw, Min. Paper size: 320 x 260mm, Max. paper size: 760 x 520mm, Max. die cutting size: 750 x 520mm, Max. die cutting pressure: 250 Tons, Inner chase size: 765 x 530mm, Die cutting Precision: +/- 0.15mm, Delivery Pile Height: 940 mm, Corrugated board up to 4mm, Central lubrication with auto pump, CE Standard Machine, Paper or cardboard thickness: 100-2000 gsm, Non-stop feeder and delivery, Feeding Pile Height: 1050mm, Automatic pressure adjustment, Min. gripper margin: 7 mm, Min. distance to 1st rule: 12 mm, Max. Speed: 10000 strokes per hour, Max. Speed with stripping: 9000 strokes per hour, Specifications are subject to change without notice.
Royo Machinery is one of the world's most experienced suppliers of new and used printing, finishing and carton converting equipment worldwide. We have sold more new and used offset printing and finishing equipment to the Caribbean and Latin American printers than any other dealer over the last 77 years. Our exceptional relationship and understanding of the region gives our company a competitive edge over competitors.
The Royo Family has accumulated the expertise to help you with the logistics and the engineering required to manage the process of buying and selling new and used printing, finishing and converting machinery anywhere in the world. We offer additional services such as pre-purchase inspections, dismantling and removal, parts, cleaning and painting, rebuilding and retrofitting, transportation, installation and demonstration, after sales service and warranty, appraisals and professional consultation.
Being in the industry since 1948 has allowed us to build a global network dedicated to finding the new or used printing, finishing and carton converting equipment you might be looking for at the most competitive prices. Let us help you find the Offset press, Paper Cutter, Folder, Die Cutter, Box Folder Gluer, UV Coater, Roll Sheeter or Laminator you are looking for.
