New Cutting Plotter Royo Machinery

Royo Machinery RZCRT-3016E
Royo Machinery RZCRT-3016E
Royo Machinery RZCRT-3016E
Royo Machinery RZCRT-3016E
Royo Machinery RZCRT-3016E
Royo Machinery RZCRT-3016E
Royo Machinery RZCRT-3016E
Royo Machinery RZCRT-3016E

Specifications

  • Equipment ID: 570
  • Type: Cutting Plotter
  • Model: RZCRT-3016E
  • Manufacturer: Royo Machinery
  • Paper Size: 3000 x 1600 mm
  • Condition: New

Features

Accuracy: +/-0.1mm, Air pump power: 9kw, Camera, Compatibility: AutoCAD CorelDraw Optitex Shoemaster RECAD Gerber etc., Cutting Speed: Straight line up to 1200mm/sec, Cutting Speed: Straight line up to 3000mm/sec, Cutting Thickness: 0.5-25 mm , Dimensions: 2480 x 1760 x 1540 mm, Divisional vacuum absorption, Electric oscillating tool, File Format: Standard DXF PLT and HPGL, Folding Carton Samplemaker, Functions: Full cut kiss cut half cut drawing and marking, Machine Language: HP-GL and GP-GL, Machine resolution: 0.01mm, Material hold down: Via vacuum, Materials: Cardboard paper PP plastic EVA magnetic corrugated board, Motor & Transmission: Servo motor with guided rail and synchronous belt, Plotting Pen, Score/creasing tool, Software resolution: 0.025mm, Specifications are subject to change without notice, Suggested HS code: 8441.10.0000, Total Power: 9.0kW 220V 50/60Hz, Touch screen LCD, Working area: 3000 x 1600mm
